Double-snap PCB support, black PA6.6 polyamide UL94-HB, PCB Ø4 mm 1.8 mm / chassis Ø4 mm 1.6 mm
66,00 €
excl. VAT
Black PA6.6 polyamide PCB support, UL94-HB fire rating. It snaps into the PCB on one side and into the chassis (or a second PCB) on the other: fitted by hand, without screws or tools. The PCB is released by pinching the tabs.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
Black PA6.6 polyamide PCB support, UL94-HB fire rating. It snaps into the PCB on one side and into the chassis (or a second PCB) on the other: fitted by hand, without screws or tools. The PCB is released by pinching the tabs.
Drawing: height 44 mm.
Specifications
| Reference | SC-F008-44-100 |
|---|---|
| Type | Double-snap PCB support |
| Material | PA6.6 polyamide, black |
| Fire rating | UL94-HB |
| PCB hole | Ø 4 mm |
| PCB thickness | 1.8 mm |
| Chassis hole | Ø 4 mm |
| Chassis thickness | 1.6 mm |
| Available heights | 44 mm |
Black PA6.6 polyamide PCB support, UL94-HB fire rating. It snaps into the PCB on one side and into the chassis (or a second PCB) on the other: fitted by hand, without screws or tools. The PCB is released by pinching the tabs.
