Round glass-fibre reinforced PA4.6 polyamide plastic spacer Ø3.6x7mm for M3.5 screw
44,40 €
excl. VAT
It keeps an accurate gap between two parts fastened by an M3.5 screw passing through its Ø 3.6 mm bore.
Polyamide: electrically insulating, light and impact resistant.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
The round polyamide (plastic) spacers are available in different lengths to suit your needs.
The spacers (plain cylindrical sleeves) are made of black glass-fibre reinforced PA4.6 polyamide. The linear tolerances are therefore: from 1 to 6 mm: ±0.1 mm; from 6 to 30 mm: ±0.2 mm; from 30 mm: ±0.3 mm.
Products compliant with the RoHS II (2011/65/EU) and RoHS III (2015/863/EU) directives and with the REACH regulation (1907/2006).
Specifications
| Reference | PA-3.5x7x2-100 |
|---|---|
| Type | Plain spacer |
| Material | Plastic PA4.6 glass-fibre reinforced, black |
| Fire rating | UL94-V0 |
| For screw | M3.5 |
| Outer Ø | 7 mm |
| Inner Ø | 3.6 mm |
| Length | 2 mm |
The round polyamide (plastic) spacers are available in different lengths to suit your needs.
