Stepped-bore spacer, black glass-fibre reinforced PA6, UL94-HB, counterbore Ø10.3 × Ø16 mm, for M5 screw
26,40 €
excl. VAT
Stepped-bore spacer for an M5 screw. Stepped bore: a wider bore on one face and a narrower hole in the bottom, open on the other side. The counterbore on the open face is Ø10.3 mm. Black glass-fibre reinforced PA6 polyamide, UL94-HB. 12 mm length: clearance hole in the bottom Ø5.2 mm, bottom 2.5 mm thick. 5 mm length: clearance hole diameter and counterbore depth not specified by the manufacturer.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
Stepped-bore spacer for an M5 screw. Stepped bore: a wider bore on one face and a narrower hole in the bottom, open on the other side. The counterbore on the open face is Ø10.3 mm. Black glass-fibre reinforced PA6 polyamide, UL94-HB. 12 mm length: clearance hole in the bottom Ø5.2 mm, bottom 2.5 mm thick. 5 mm length: clearance hole diameter and counterbore depth not specified by the manufacturer.
Specifications
| Reference | DS-F002-5-100 |
|---|---|
| Type | Stepped-bore spacer |
| Material | PA6 polyamide, 25% glass-fibre reinforced, black |
| Fire rating | UL94-HB |
| Counterbore diameter (open face) | Ø 10.3 mm |
| Clearance hole diameter (bottom), 12 mm length | Ø 5.2 mm |
| Bottom thickness, 12 mm length | 2.5 mm |
| Clearance hole and counterbore depth, 5 mm length | Not specified by the manufacturer |
| Outer diameter | Ø 16 mm |
| For screw | M5 |
| Available lengths | 5 · 12 mm |
Stepped-bore spacer for an M5 screw. Stepped bore: a wider bore on one face and a narrower hole in the bottom, open on the other side. The counterbore on the open face is Ø10.3 mm. Black glass-fibre reinforced PA6 polyamide, UL94-HB. 12 mm length: clearance hole in the bottom Ø5.2 mm, bottom 2.5 mm thick. 5 mm length: clearance hole diameter and counterbore depth not specified by the manufacturer.
