Hexagonal insulated standoff male/female polyester plastic, steel insert, M8 - 21 mm across flats
€226.60 tax excl.
€226.60
Tax included
Its M8 stud screws into a tapped part or into another spacer; the next part is fixed by a M8 screw in its tapped end.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
Delivery5 to 10 days
Shipping 22.00 € excl. VATFree from 400 € excl. VAT
Insulated standoff in polyester plastic with one M8 tapped insert (8 mm deep) and one M8 threaded stud, 10 mm long in steel, moulded into the part.
PlasticSteel
Specifications
| Reference | PES-MF-M8-SW21-L26-T10-10 |
|---|---|
| Type | Male-female |
| Material | Plastic polyester, steel insert |
| Thread | M8 |
| Across flats | 21 mm |
| Body length | 26 mm |
| Stud length | 10 mm |
| Tapping | depth 8 mm |
Insulated standoff in polyester plastic with one M8 tapped insert (8 mm deep) and one M8 threaded stud, 10 mm long in steel, moulded into the part.
