Hexagonal insulated standoff male/female polyester plastic, steel insert, M8 - 21 mm across flats
1 292,20 €
excl. VAT
Its M8 stud screws into a tapped part or into another spacer; the next part is fixed by a M8 screw in its tapped end.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
Insulated standoff in polyester plastic with one M8 tapped insert (8 mm deep) and one M8 threaded stud, 10 mm long in steel, moulded into the part.
Insulated standoff in polyester plastic with one M8 tapped insert (8 mm deep) and one M8 threaded stud, 10 / 20 mm long in steel, moulded into the part.
PlasticSteel
Specifications
| Reference | PES-MF-M8-SW21-L35-T20-50 |
|---|---|
| Type | Male-female |
| Material | Plastic polyester, steel insert |
| Thread | M8 |
| Across flats | 21 mm |
| Body length | 35 mm |
| Stud length | 20 mm |
| Tapping | depth 8 mm |
Insulated standoff in polyester plastic with one M8 tapped insert (8 mm deep) and one M8 threaded stud, 10 mm long in steel, moulded into the part.
