Hexagonal insulated standoff male/female PA6.6 plastic, brass insert, UL94-V2 M4 - 8 mm across flats
194,80 €
excl. VAT
Its M4 stud screws into a tapped part or into another spacer; the next part is fixed by a M4 screw in its tapped end.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
Insulated standoff in PA6.6 plastic with one M4 tapped insert (6 mm deep) and one M4 threaded stud, 8 mm long in brass, moulded into the part. Flammability class UL94-V2.
PlasticPA6.6UL94-V2Brass
Specifications
| Reference | P66-MF-M4-SW8-L23-T8-100 |
|---|---|
| Type | Male-female |
| Material | Plastic PA6.6, brass insert |
| Fire rating | UL94-V2 |
| Thread | M4 |
| Across flats | 8 mm |
| Body length | 23 mm |
| Stud length | 8 mm |
| Tapping | depth 6 mm |
Insulated standoff in PA6.6 plastic with one M4 tapped insert (6 mm deep) and one M4 threaded stud, 8 mm long in brass, moulded into the part. Flammability class UL94-V2.
