Round insulated standoff male/female PA6.6 plastic, brass insert, M4 - Ø8 mm
152,20 €
excl. VAT
Its M4 stud screws into a tapped part or into another spacer; the next part is fixed by a M4 screw in its tapped end.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
Insulated standoff in PA6.6 plastic with one M4 tapped insert (6 mm deep) and one M4 threaded stud, 6 mm long in brass, moulded into the part. Flammability class UL94-HB.
PlasticPA6.6Brass
Specifications
| Reference | P66-MF-M4-D8-L13-T6-100 |
|---|---|
| Type | Male-female |
| Material | Plastic PA6.6, brass insert |
| Fire rating | UL94-HB |
| Thread | M4 |
| Outer Ø | 8 mm |
| Body length | 13 mm |
| Stud length | 6 mm |
| Tapping | depth 6 mm |
Insulated standoff in PA6.6 plastic with one M4 tapped insert (6 mm deep) and one M4 threaded stud, 6 mm long in brass, moulded into the part. Flammability class UL94-HB.
