Round insulated standoff male/female PA6.6 plastic, brass insert, M8 - Ø19 mm
47,80 €
excl. VAT
Its M8 stud screws into a tapped part or into another spacer; the next part is fixed by a M8 screw in its tapped end.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
Insulated standoff in PA6.6 plastic with one M8 tapped insert (14 mm deep) and one M8 threaded stud, 14.8 mm long in brass, moulded into the part.
Insulated standoff in PA6.6 plastic with one M8 tapped insert (14 mm deep) and one M8 threaded stud, 14 / 14.8 mm long in brass, moulded into the part. Flammability class UL94-HB.
PlasticPA6.6Brass
Specifications
| Reference | P66-MF-M8-D19-L35-T14.8-10 |
|---|---|
| Type | Male-female |
| Material | Plastic PA6.6, brass insert |
| Fire rating | UL94-HB |
| Thread | M8 |
| Outer Ø | 19 mm |
| Body length | 35 mm |
| Stud length | 14.8 mm |
| Tapping | depth 14 mm |
Insulated standoff in PA6.6 plastic with one M8 tapped insert (14 mm deep) and one M8 threaded stud, 14.8 mm long in brass, moulded into the part. Flammability class UL94-HB.
