Hexagonal insulated standoff male/female PA6 plastic, brass insert, M3 - 7 mm across flats
127,40 €
excl. VAT
Its M3 stud screws into a tapped part or into another spacer; the next part is fixed by a M3 screw in its tapped end.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
Insulated standoff in PA6 plastic with one M3 tapped insert (4 mm deep) and one M3 threaded stud, 6 mm long in brass, moulded into the part. Flammability class UL94-HB.
PlasticPA6Brass
Specifications
| Reference | PA6-MF-M3-SW7-L7-T6-100 |
|---|---|
| Type | Male-female |
| Material | Plastic PA6, brass insert |
| Fire rating | UL94-HB |
| Thread | M3 |
| Across flats | 7 mm |
| Body length | 7 mm |
| Stud length | 6 mm |
| Tapping | depth 4 mm |
Insulated standoff in PA6 plastic with one M3 tapped insert (4 mm deep) and one M3 threaded stud, 6 mm long in brass, moulded into the part. Flammability class UL94-HB.
