Hexagonal insulated standoff male/female PA6 plastic, brass insert, M2.5 - 6 mm across flats
€276.00 tax excl.
€276.00
Tax included
Its M2.5 stud screws into a tapped part or into another spacer; the next part is fixed by a M2.5 screw in its tapped end.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
Delivery5 to 10 days
Shipping 22.00 € excl. VATFree from 400 € excl. VAT
Insulated standoff in PA6 plastic with one M2.5 tapped insert (3.8 mm deep) and one M2.5 threaded stud, 6 mm long in brass, moulded into the part. Flammability class UL94-HB.
PlasticBrass
Specifications
| Reference | PA6-MF-M2.5-SW6-L7-100 |
|---|---|
| Type | Male-female |
| Material | Plastic PA6, brass insert |
| Thread | M2.5 |
| Across flats | 6 mm |
| Body length | 7 mm |
| Stud length | 6 mm |
| Tapping | depth 3.8 mm |
Insulated standoff in PA6 plastic with one M2.5 tapped insert (3.8 mm deep) and one M2.5 threaded stud, 6 mm long in brass, moulded into the part. Flammability class UL94-HB.
