Hexagonal insulated standoff female/female PA6.6 plastic, brass insert, M4 - 8.4 mm across flats
€368.00 tax excl.
€368.00
Tax included
Two M4 screws tighten into its ends to hold two parts apart, for instance a circuit board on its mounting.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
Delivery5 to 10 days
Shipping 22.00 € excl. VATFree from 400 € excl. VAT
Insulated standoff in PA6.6 plastic with two M4 tapped inserts (6 mm deep) in brass, moulded into the part. Flammability class UL94-HB.
PlasticBrass
Specifications
| Reference | P66-FF-M4-SW8.4-L15-100 |
|---|---|
| Type | Female-female |
| Material | Plastic PA6.6, brass insert |
| Thread | M4 |
| Across flats | 8.4 mm |
| Length | 15 mm |
| Tapping | depth 6 mm |
Insulated standoff in PA6.6 plastic with two M4 tapped inserts (6 mm deep) in brass, moulded into the part. Flammability class UL94-HB.
