Hexagonal insulated standoff female/female PA6.6 plastic, brass insert, M5 - 10 mm across flats
389,40 €
excl. VAT
Two M5 screws tighten into its ends to hold two parts apart, for instance a circuit board on its mounting.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
Insulated standoff in PA6.6 plastic with two M5 tapped inserts (6 mm deep) in brass, moulded into the part. Flammability class UL94-V2.
PlasticPA6.6Brass
Specifications
| Reference | P66-FF-M5-SW10-L35-100 |
|---|---|
| Type | Female-female |
| Material | Plastic PA6.6, brass insert |
| Thread | M5 |
| Across flats | 10 mm |
| Length | 35 mm |
| Tapping | depth 6 mm |
Insulated standoff in PA6.6 plastic with two M5 tapped inserts (6 mm deep) in brass, moulded into the part. Flammability class UL94-V2.
