Round insulated standoff female/female PA6.6 plastic, brass insert, M2.5 - Ø6.5 mm
€340.00 tax excl.
€340.00
Tax included
Two M2.5 screws tighten into its ends to hold two parts apart, for instance a circuit board on its mounting.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
Delivery5 to 10 days
Shipping 22.00 € excl. VATFree from 400 € excl. VAT
Insulated standoff in PA6.6 plastic with two M2.5 tapped inserts (6 mm deep) in brass, moulded into the part. Flammability class UL94-HB.
PlasticBrass
Specifications
| Reference | P66-FF-M2.5-D6.5-L16.5-100 |
|---|---|
| Type | Female-female |
| Material | Plastic PA6.6, brass insert |
| Thread | M2.5 |
| Outer Ø | 6.5 mm |
| Length | 16.5 mm |
| Tapping | depth 6 mm |
Insulated standoff in PA6.6 plastic with two M2.5 tapped inserts (6 mm deep) in brass, moulded into the part. Flammability class UL94-HB.
