Hexagonal insulated standoff female/female PA6 plastic, brass insert, M2.5 - 6 mm across flats
124,00 €
excl. VAT
Two M2.5 screws tighten into its ends to hold two parts apart, for instance a circuit board on its mounting.
Plastic with moulded metal inserts: it electrically insulates the two fastenings.
Secure paymentCard, transfer, PayPal
DeliveryEstimated delivery: 5 to 10 working days
Shipping from 10.90 € excl. VAT
Insulated standoff in PA6 plastic with two M2.5 tapped inserts (4 mm deep) in brass, moulded into the part. Flammability class UL94-HB.
PlasticPA6Brass
Specifications
| Reference | PA6-FF-M2.5-SW6-L10-100 |
|---|---|
| Type | Female-female |
| Material | Plastic PA6, brass insert |
| Fire rating | UL94-HB |
| Thread | M2.5 |
| Across flats | 6 mm |
| Length | 10 mm |
| Tapping | depth 4 mm |
Insulated standoff in PA6 plastic with two M2.5 tapped inserts (4 mm deep) in brass, moulded into the part. Flammability class UL94-HB.
